Devilink 140F1137 FT
The Devilink FT (Floor Thermostat) is a device for switching heating elements and other electrical equipment ON/OFF. All communication in the Devilink System is wireless and off this reason very easy to install. When using Devilink FT as heating control, it is recommended to install the device with either a floor sensor or with Devilink RS to ensure the required comfort and convenience. Furthermore if combining both the floor sensor and the Devilink RS it would fully integrate the adaptive function to the system. Secondly, you have the option to use the Devilink FT as ON/OFF switch for other electrical equipment e.g. as electrical radiators, lights or other switching units, manually or by schedule. Devilink FT is to be mounted.
To be used with the Devi CC Central Controller.
View our range of Danfoss products at Underfloor Store.
Operation voltage | 180-250 V AC, 50 Hz | Transmission power Max. | 1 mW |
Standby power consumption | < 1W | Relay switching 1 pole | 1 pole |
Resistive load | 230 V ~ 15 A/3450 W | IP class | 31 |
Inductive load | Cos Φ = 0,3 max. 4 A | Dimension (H/W/D) | 85 mm 85 mm 21 mm |
Regulation PWM – Pulse Wide Modulation | PWM – Pulse Wide Modulation | Operation voltage | < 1W |
Sensing unit NTC 15 kOhm AT 25°C | NTC 15 kOhm AT 25°C | Resistive load | 230 V ~ 15 A/3450 W |
Sensing values 0°C/20°C/50°C | 42 kOhm/18 kOhm /6 kOhm | Inductive load | Cos Φ = 0,3 max. 4 A |
Transmission frequency 868,42 MHz | 868,42 MHz | Sensor failure monitoring | Built-in monitoring |
Transmission range in normal buildings | Up to 30 m |
